Description
Should you adjust to your gun …or should it adjust to you?  The new Maxum Impact allows the shooter to adjust all critical specifications making it easy to fine tune the gun to their shooting style.  Point-of-impact, overall weight, stock fit, trigger system, recoil characteristics, and balance are all customizable. The geometry of the Impact allows for an upright shooting stance, making your gun mount more comfortable while reducing felt recoil. The result is less strain on your neck and shoulders allowing you to concentrate on only the target. The 17mm tall tapered rib dramatically increases target visibility.

The Impact is the world’s most versatile clay target gun carefully designed for the worlds best competitors.
Specifications
ModelMaxum Impact SportingMaxum Impact SportingMaxum Impact Type T (Trap)
*Measured from the lowest point of the barrel.
**Weights may vary based on wood density.
Gauge122012
Barrel length30"(76cm), 32"(81cm), 34"(86cm)32"(81cm),34"(86cm)
Avg. Weight**8lbs. 5ozs, 8lbs. 6ozs, 8lbs. 7oz, Up to 9lbs. 4ozs with DTS Kinetic Balancer™ and heavy rib torsion rods.7lbs. 11 oz8lbs. 12oz.
Receiver finishHand polished coin finish with Invisalloy™ protective finishHand polished coin finish with Invisalloy™ protective finishSatin blued finish with Invisalloy™ clear protection
Stock FinishHand rubbed oilHand rubbed oilHand rubbed oil
Checkering26 lines per inch26 lines per inch26 lines per inch
Recoil PadBlack rubberBlack rubberBlack rubber
Chamber2.75"2.75"2.75"
Top Rib11 - 9.6mm tapered. Adjustable from 50/50 low to 90/10 high.11 - 9.6mm tapered. Adjustable from 50/50 low to 90/10 high.11 - 9.6mm tapered. Adjustable from 50/50 low to 90/10 high.
Rib Height*17mm17mm17mm
Center RibVentilatedVentilatedVentilated
Forcing Cones5” DuoCon5” DuoCon5” DuoCon
Avg. Bore.735, chrome lined.735, chrome lined.735, chrome lined
Chokes6 MAXIS competition chokes6 competition chokes6 MAXIS competition chokes
Sight(s)White Bradley style front, Silver center beadWhite Bradley style front, silver center beadWhite Bradley style front, Silver center bead
Fore-endRoundedRoundedSemi-beavertail with finger grooves
TriggerNew DTS trigger system with two trigger pull weight options, take up, over travel and length of pull adjustments. Factory selective release triggers available in single and double release for 12g.New DTS trigger system with two trigger pull weight options, take up, over travel and length of pull adjustments. New DTS trigger system with two trigger pull weight options, take up, over travel and length of pull adjustments. Factory selective release triggers available in single and double release for 12g.
SafetyManual (Automatic as an option)Manual (Automatic as an option)Manual (Automatic as an option)
AccessoriesStock and trigger wrench, choke case, friction choke wrenchStock and trigger wrench, choke case, friction choke wrenchStock and trigger wrench, choke case, friction choke wrench
CasePlastic hard case with fit interior and velvet stock sleeve and barrel sleevePlastic hard case with fit interior and velvet stock sleeve and barrel sleevePlastic hard case with fit interior and velvet stock sleeve and barrel sleeve
Stock Dimensions
ModelMaxum Impact 12Maxum Impact 20Maxum Impact 12 Type T
All Measurements are subject to change without notice and are based on average measurements. - See more at: https://gueriniusa.com/shotguns/forum/#sthash.dVhDazor.dpuf *Measured from the center of trigger adjustment.
Drop at comb* 1.6" 1.6" 1.6"
Drop at Monte Carlo* 1.8"1.8"1.8"
Drop at heel 2.25" 2.25" 2.25"
Length of pull 14.75"14.75"14.75"
Cast at heel .12".12".12"
Cast at toe .2".2".2"
Pitch
Breech to comb7.27.27.2
Reach*4.25*4.25*4.25
MSRP Pricing
ItemDescriptionMSRP
*Pricing is subject to change. If your desired configuration is not listed, please contact your dealer for a Special Order.
A24140Maxum Impact 12g 30" Barrels$8,620
A24150Maxum Impact 12g 32" Barrels$8,620
E34160Maxum Impact Trap 12g 34" Barrels - Unsingle$8,620
E34880Maxum Impact Trap 12g, 32" 34" Barrels Combo - Unsingle$11,050
Additional Charge for Left Hand Stock (left handed stock is not available in 20ga Maxum Impact)$230
