Description
The Summit Ascent is everything you want from a modern sporting clays shotgun without the additional cost of an adjustable point-of-impact rib. The 10mm high tapered top rib is designed to shoot at 50/50% point-of-impact allowing for an upright shooting position and improved target visibility, making it the perfect Sporting Clays gun. The stock incorporates the DTS adjustable comb to make sure a variety of shooters can adjust the gun to fit precisely. The mass in the stock and barrels are engineered so the gun will balance perfectly. With a long list of winning features the Ascent is taking sporting clays to the next level.
Specifications
Model | Summit Ascent |
---|---|
Gauge | 12 |
Barrel length | 30" (76cm), 32" (81cm) |
Avg. Weight** | 8lbs. 4oz., 8 lbs. 6oz. |
Receiver finish | Satin blued finish with Invisalloy™ clear protection |
Stock Finish | Hand rubbed oil |
Checkering | 26 lines per inch |
Recoil Pad | Black rubber |
Chamber | 2 3/4" |
Top Rib | Width 10mm - 8mm Tapered |
Rib Height* | 10mm Fixed |
Center Rib | Ventilated |
Forcing Cones | 5" DuoCon |
Avg. Barrel Weight | 30"-1.49kg (3.28lbs.) 32"-1.52kg (3.35lbs.) |
Avg. Bore | .735, Chrome lined |
Chokes | 6 MAXIS competition chokes |
Sight(s) | White Bradley style front Silver center bead |
Fore-end | Rounded |
Trigger | New DTS trigger system with two trigger pull weight options, take up, over travel and length of pull adjustments. Factory selective release triggers available in single and double release for 12g. |
Safety | Manual (Automatic as an option) |
Accessories | Stock and trigger wrench, choke case, friction choke wrench |
Case | Plastic hard case with fit interior and velvet stock sleeve and barrel sleeve |
*Measured from the lowest point of the barrel. **Weights may vary based on wood density. |
|
Overall length of gun w/ chokes | 48.25” (30” barrels), 50.25” (32” barrels) |
Stock Dimensions
Model | Summit Ascent 12 |
---|---|
Drop at comb | 1.75" |
Drop at Monte Carlo | 2" |
Drop at heel | 2.5" |
Length of pull | 14.75" |
Cast at heel | .125" |
Cast at toe | .25" |
Pitch | 5° |
Breech to comb | 7.5" |
Reach* | 4" (adjustable) |
All Measurements are subject to change without notice and are based on average measurements. *Measured from the center of trigger adjustment. |
MSRP Pricing
Item | Description | MSRP |
---|---|---|
A2H145 | Summit Ascent Sporting 12g 30" Barrels | $6,050 |
A2H155 | Summit Ascent Sporting 12g 32" Barrels | $6,050 |
Additional Charge for Left Hand Stock | $285 | |
*Pricing is subject to change. If your desired configuration is not listed, please contact your dealer for a Special Order. |
